Turismo Piccolo 125i
124.6 CC
Displacement
0
"
Wheel Size
0
km./h
Top Speed
12V 9Ah
Battery
Technical Specifications
| Dimension | 1790 mm (Length) x 680 mm (Width) x 1100 mm (Height) |
| Wheelbase | 1350 mm |
| Dry Weight | 125 kg |
| Max Load | 169 kg |
| Ground Clearance | 330 mm |
| Seat Height | 770 mm |
| Displacement | 124.6 cc |
| Engine Type | Single Cylinder, Air Cooled, 4T, 2V SOHC |
| Bore x Stroke | 52.4 mm x 57.8 mm |
| Compression Ratio | 10.5:1 |
| Max. net power, rate | 7.25 kW @ 7,300 rpm (Rear wheel) |
| Max. net torque, rate | 9.67 Nm @ 7,200 rpm (Rear wheel) |
| Maximum speed | 85 km/h |
| Ignition | Inductive |
| Starting Method | Electric |
| Fuel injection | Electronic injection |
| Chassis | Space frame tubular chassis with Steel & ABS bodywork |
| Front suspension | Double hydraulic preload adjustable shock absorber with coil spring and anti-dive linkage system |
| Rear suspension | Coil spring with adjustable preload (4 positions) hydraulic shock absorber |
| Front Tyre | Tubeless 110/70-12 |
| Rear Tyre | Tubeless 120/70-12 |
| Brake system | (Front) 220 mm, Disc / (Rear) Disc 200 mm |
| Battery | 12 volts |
| Euro exhaust standard | Euro 4 |
| Fuel Tank Capacity | 11 L |
